Encoders Incremental
Sendix 5000
|
|
The Standard Encoder for automation.
Sendix 5000 / 5020 incremental encoders offer special resistance to vibrations and installation error due to their robust bearing construction using the Safety Lock™ design. The stable die-cast housing, the high protection up to IP67 and the wide temperature range from -40 °C to +85 °C allow universal use. This family of encoders is subject to continuous technical development and now offers a unique variety of ordering options.
| Mechanical | |
|---|---|
| Dimension | Ø 50 mm |
| Shaft type |
6 mm shaft, with flat surface 8 mm shaft, with flat surface 10 mm shaft, with flat surface 11 mm shaft, with flat surface 12 mm shaft, with flat surface 1/4 " shaft, with flat surface 3/8 " shaft, with flat surface |
| Flange type |
Synchro flange / Servo flange Clamping flange Square flange Euro flange Ø 50.80 mm ❏ 52.30 mm Ø 58.00 mm Ø 63.50 mm ❏ 63,50 mm Ø 115.00 mm |
| Working temperature | -40 °C ... +85 °C |
| Protection level |
IP65 IP66 IP67 |
| Connection types |
Axial cable Radial cable M23 connector axial M23 connector radial M12 connector axial M12 connector radial MIL connector |
| Max. rotational speed |
12.000 min-1 |
| Weight | 400 g |
| Electrical | |
|---|---|
| Scanning | optical |
| Resolution max. |
5.000 ppr incremental |
| Power supply |
5 V DC 5...30 V DC 10...30 V DC |
| Interfaces |
Gegentakt TTL / RS422 Open Collector |
| Options | |
|---|---|
| on request |
|
Robust performance
- Increased resistance to vibrations and installation error, avoidance of machine downtime and repairs due to robust bearing construction using the Safety Lock™ design.
- Remains leak-free even in rough everyday use, offers high safety against field failures and is suitable for outdoor use thanks to a stable die-cast housing and protection up to IP67.
- Captive clamping ring for hollow shaft encoders.
- Wide temperature range -40°C to +85°C.
- Suitable connection variant for every specific case:
- cable connection with different standard lengths, M12 (5- or 8-pin), M23 (12-pin), MIL (7- or 10-pin) and Sub-D connector.In addition: Variants with connector fitted in the cable – for error-free electrical connection to your control.
- Reliable mounting in a wide variety of installation situations: comprehensive and proven fixing possibilities.
- Compatible with all US and European standards.
- Wide range of standard pulse ranges up to max. 5000 pulses per revolution.
Accessories
Bellows coupling
Bellows couplings are used for the cost-optimized connection of motor and encoder. In addition, a correction of angular errors between drive and encoder is achieved. Compensation for larger axial errors.Bellows coupling (stainless steel).
| 8.0000.1202.XXXX |
Assembly bell
For shaft encoders with flange ø 50 ... 58 mmFast encoder mounting. Electrical and thermal insulation through glass-fibre reinforced plastic and insulating spring washer coupling - complete delivery as a set.
Scope of delivery
- Mounting bell
- Spring washer coupling (8.0000.1401.XXXX)
- Mounting eccentric (8.0000.4B00.0000)
- Mounting accessories
| 8.0000.4500.XXYY |
Adapter flange, square, 4 mm
For shaft encoders with clamping flange ø 50 ... 58 mmScope of delivery
- Flange adapter (aluminium)
- 3 screws for mounting on the encoder
Connection to the application (not included in delivery)
- 4 screws
| 58,0 mm x 4 mm | 8.0010.2100.0000 |
| 63,5 mm x 3 mm | 8.0010.2120.0000 |
| 70,0 mm x 10 mm | 8.0010.2600.0000 |
| 80,0 mm x 4 mm | 8.0010.2800.0000 |
Flange, Ø 115mm Euroflange
For shaft encoders with flange ø 50 ... 58 mmScope of delivery
- Flange adapter (aluminium)
- 3 screws for fastening to the encoder
Connection to the application (not included in delivery)
- 6 screws
| Drehgeber 580x/5000 | 8.0010.2160.0000 |
Flange, Ø 58mm
For shaft encoders with flange ø 50 ... 58 mmAdapter for converting a clamping flange into a synchro flange.
Scope of delivery
- Flange adapter (aluminium)
- 3 screws for mounting on the encoder
Connection to the application (not included in delivery)
- 3 screws
| 8.0010.2180.0000 |
Flange, Ø 65mm
For shaft encoders with flange ø 50 ... 58 mmWith this flange adapter, Kübler encoders of size 58 mm can replace third-party encoders of size 65 mm.
Scope of delivery
- Flange adapter (aluminium)
- 3 screws for mounting on the encoder
Connection to the application (not included in delivery)
- 3 screws
| 8.0010.2230.0000 |
Flange, Ø 90mm
For shaft encoders with flange ø 50 ... 58 mmAdapter for converting a clamping flange into a synchro flange. Mechanically compatible with encoder type 9000.
Scope of delivery
- Flange adapter (aluminium)
- 3 screws for fastening to the encoder
Connection to the application (not included in delivery)
- 6 screws
| 8.0010.2270.0000 |
Angular flange
For shaft encoders with flange ø 50 ... 58 mmScope of delivery
- Angle flange (aluminium)
- 3 screws for fastening to the encoder.
Connection to the application (not included in delivery)
- 2 screws
| 8.0010.2300.0000 |
Isolation insert, hollow shaft Ø 15mm
Thermal and electrical insulation of the encoders (temperature range -40°C to +115°C). These insulating inserts prevent currents through the encoder bearings. These can occur when used with inverter-controlled three-phase or AC vector motors and considerably shorten the service life of the encoder bearings. In addition, the encoder is thermally insulated because the plastic does not transfer the heat to the encoder.Insulation insert (plastic).
| Innendurchmesser 8 mm | 8.0010.4020.0000 |
| Innendurchmesser 6 mm | 8.0010.4021.0000 |
| Innendurchmesser 1/4" | 8.0010.4022.0000 |
| Innendurchmesser 10 mm | 8.0010.4023.0000 |
| Innendurchmesser 3/8" | 8.0010.4024.0000 |
| Innendurchmesser 12 mm | 8.0010.4025.0000 |
| Innendurchmesser 1/2" | 8.0010.4026.0000 |
Bearing box
For shaft encoder with clamping flange ø 58 mm and shaft 10 x 20 mmWhen the encoder is driven by a toothed or chain wheel, V-belt or toothed belt, impeller, etc., the permissible axial or radial shaft loads are usually exceeded during operation. For these cases, the bearing box equipped with reinforced bearings is ideally suited.
Scope of delivery
- Bearing box with lock and O-ring
- Coupling for shaft 10 mm
- Adapter flange 8.0010.2100.0000
- Mounting accessories
| 8.0010.8200.0004 |
Robust bearing unit
For shaft encoders with clamping flange ø 50 ... 58 mm and shaft 10 mmThe separation of the bearing load and the sensor system provides the encoder with additional protection in harsh environments.
Scope of delivery
- Robust bearing unit
- 3 x cheese head screw M4x25 (SW3)
- 1 x O-ring
| 8.0010.8200.000C |
